HP UPS Network Module User Manual

Overview 8
Item Description
1
UPS with an HP UPS Network Module
2
HPPP Client server
3
HPPP Client server
4
HPPP Client server
5
Network
6
Remote workstation browsing into the HP UPS Network
Module or HPPP Client over the network
Green
Power connection
Red
Communication path
Configuration B
This figure illustrates one or more HPPP Clients are redundantly powered by two UPSs and communicate with
two UPS Network Modules over the network to begin a graceful shutdown in the event of a power failure or
other configured shutdown events.
NOTE: Up to 35 HPPP Clients can be managed by one HP UPS Network Module.
