Table 3-1 Computer major component descriptions and part numbers
Item Component Spare part number
(1) Display assembly
NOTE: Display spare parts are available only as subcomponents. For spare part information, see Display assembly
subcomponents on page 21.
(2) Top cover with keyboard
NOTE: For a detailed list of country codes, see Top cover with keyboard on page 63.
Ceramic white N13297-xx1
Mica silver N13298-xx1
Performance blue N13299-xx1
(3) Heat sink assembly
For use in models with RTX 3050 or 3050Ti N13305-001
For use in models with GTX 1650 graphics N13306-001
(4) Fan assembly N13304-001
(5) Speakers N13315-001
(6) Touchpad
NOTE: The touchpad cable is available as spare part number N13312-001.
Ceramic white N13309-001
Mica silver N13310-001
Performance blue N13311-001
(7) Touchpad bracket not available as a
spare part
(8) System board
NOTE: The system board repair kit is available as spare part number N18865-888.
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
Intel Core i7-12700H processor and NVIDIA GeForce RTX 3050 Ti graphics N13292-xx1
Intel Core i7-12700H processor and NVIDIA GeForce RTX 3050 graphics N13290-xx1
Intel Core i7-12700H processor and NVIDIA GeForce GTX 1650 graphics N13288-xx1
Intel Core i7-12650H processor and NVIDIA GeForce RTX 3050 Ti graphics N15770-xx1
Intel Core i7-12650H processor and NVIDIA GeForce RTX 3050 graphics N15768-xx1
Intel Core i5-12500H processor and NVIDIA GeForce RTX 3050 Ti graphics N13291-xx1
Intel Core i5-12500H processor and NVIDIA GeForce RTX 3050 graphics N13289-xx1
Intel Core i5-12500H processor and NVIDIA GeForce GTX 1650 graphics N13287-xx1
Intel Core i5-12450H processor and NVIDIA GeForce RTX 3050 Ti graphics N15769-xx1
Intel Core i5-12450H processor and NVIDIA GeForce RTX 3050 graphics N15767-xx1
Computer major components 19
