Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
Intel Core i5-12450H processor and NVIDIA GeForce GTX 1650 graphics N15766-xx1
(9) Battery
IMPORTANT: To avoid damage to the system board, be sure to use the correct battery for the
graphics used in the computer.
4 cell, 70 Whr, for use in models with GeForce RTX 3050 or 3050 Ti graphics M39179-005
3 cell, 52.5 Whr, for use in models with GeForce GTX 1650 graphics L84394-005
(10) Dummy n N13308-001
(11) Bottom cover
Ceramic white N13316-001
Mica silver N13317-001
Performance blue N13318-001
(12) I/O board
NOTE: The I/O board cable is available as spare part number N13301-001.
N13300-001
(13) I/O board bracket not available as a
spare part
(14) WLAN module
Intel AX211 Wi-Fi 6e Bluetooth 5.2 WLAN M53366-005
Mediatek Wi-Fi 6 MT7921 + Bluetooth 5.2 M74879-005
(15) Card reader
NOTE: The card reader cable is available as spare part number N13303-001.
N13302-001
(16) Solid-state drive (PCIe-4 × 4)
1 TB M16560-001
512 GB M17436-001
256 GB M52025-001
(17) Memory module (DDR4-3200)
8 GB L46598-001
4 GB L83673-001
(18) Plastic rear vent N13307-001
* Power connector and cable N13314-001
* RJ-45 (network) jack door
Ceramic white N13335-001
Mica silver N13336-001
Performance blue N13337-001
20 Chapter 3Illustrated parts catalog
