Product specifications
Physical characteristics
Weight
With stand (non-touch)
With stand (touch)
19.2 kg (42.3 lbs)
21.0 kg (46.3 lbs)
Without stand (non-touch)
Without stand (touch)
13.3 kg (29.3 lbs)
15.1 kg (33.3 lbs)
Stand only 5.9 kg (13.0 lbs)
Dimensions
Upright, including stand Height: 533.4 mm (21.0 in)
Width: 660.4 mm (26.0 in)
Depth: 419.1 mm (16.5 in)
Unit only Height: 457.2 mm (18.0 in)
Width: 660.4 mm (26.0 in)
Depth: 81.3 mm (3.2 in)
Environmental specifications
Temperature
Operating: 5°C to 35°C (40°F to 95°F)
Non-operating: -40°C to 60°C (-40°F to 140°F)
NOTE: The ambient upper limit of 35°C is good up to 1524 m (5000 ft) elevation. Derate by 1°C for
every 305 m (1000 ft) above 1524 m (5000 ft). For example, at 3,048 m (10,000 ft), the upper
ambient air temperature limit is 30°C.
Humidity
Operating: 8% to 85% relative humidity, non-condensing
Non-operating: 8% to 90% relative humidity, non-condensing
Altitude
Operating: 0 to 3,048 m (10,000 ft)
Non-operating: 0 to 9,144 m (30,000 ft)
Shock
Operating: ½-sine: 40g, 2-3ms (~62 cm/sec)
Non-operating:
●
½-sine: 160 cm/s, 2-3ms (~105g)
●
20g, square: 422 cm/s
NOTE: Values represent individual shock events and do not indicate repetitive shock events.
Vibration
Operating random: 0.5g (rms), 5-300 Hz, up to 0.0025 g
2
/Hz
Non-operating random: 2.0g (rms), 5-500 Hz, up to 0.0150 g
2
/Hz
NOTE: Values do not indicate continuous vibration.
Product specifications 9
