Supported RAID configurations
All workstation platforms have the following controllers:
●
LSI 2308 controllers — HP Z840 Workstations
●
LSI 9217-4i4e controllers — HP Z440 and Z640 Workstations (optional)
●
LSI 9270-8i controllers — HP Z440, Z640, and Z840 Workstations (optional)
The following RAID configurations are supported:
Configuration Description Controllers
RAID 0
Integrated striped disk
array
●
Requires a minimum of two drives.
●
Provides improved I/O performance.
●
Provides no fault tolerance.
●
Loses all data if any disk in the array fails.
●
Increases disk performance.
●
Intel with RSTe
●
LSI 2308
●
LSI 9217-4i4e
●
LSI 9270-8i
RAID 1
Mirrored disk array
●
Supports a maximum of two drives.
●
Provides 100% redundancy: all data from one drive
is duplicated on a second drive.
●
Recovers from a single-drive failure.
●
Serves as a good entry-level redundant system.
●
Intel with RSTe
●
LSI 2308
●
LSI 9217-4i4e
●
LSI 9270-8i
RAID 5
Striped disk array with
distributed parity
●
Supports three or more drives.
●
Provides fault tolerance and I/O performance
improvement, especially for write-biased
applications.
●
Retains all data if a single drive fails, but
performance is compromised and data loss is
possible if a second drive fails until the failed drive
is replaced and the array rebuilt.
●
Intel with RSTe
●
LSI 9270-8i
RAID 10
Striped and mirrored
disk array
●
Supports four or more drives.
●
Requires an even number of drives.
●
Provides excellent performance.
●
Uses several drives to stripe data, then copies the
striped drives to provide redundancy.
●
Offers high data transfer of striped arrays and
provides increased data accessibility (reads).
●
Intel with RSTe
●
LSI 2308
●
LSI 9217-4i4e
●
LSI 9270-8i
RAID 1E
Two-way mirroring
●
Provides benefits comparable to RAID 10.
●
Requires an odd number of drives.
●
Requires a minimum of three drives.
●
Delivers improved read performance.
●
LSI 2308
●
LSI 9217-4i4e
106 Appendix B Configuring RAID devices
