HP Z440 Workstations — Intel AHCI SATA controller guidelines
See
HP Z440 Workstation system board components on page 5 to determine the location of system board
connectors.
NOTE: Port 0 is the default port for the boot drive (the default port can be changed manually in the BIOS).
RAID card (RC) or system
board (SB) connector
Drive installation scenarios
123
RC J8
SAS HDD 1 SAS HDD 1-B SATA HDD 1-B
RC J7 SAS HDD 2 SATA HDD 2-D SAS HDD 2-D
RC J6 SAS HDD 3 SATA HDD 3-D SAS HDD 3-D
RC J5 SAS HDD 4 SATA HDD 4-D SAS HDD 4-D
SB SATA 0 — — —
SB SATA 1 — — —
SB SATA 2 ODD 1 ODD 1 ODD 1
SB SATA 3 ODD 2 ODD 2 ODD 2
SB SATA 4 eSATA (top) eSATA (top) eSATA (top)
SB SATA 5 eSATA (bottom) eSATA (bottom) eSATA (bottom)
eSATA = external SATA (2 ports per cable assembly)
HDD = hard drive
ODD = optical drive
NOTE: Only the most common configurations are shown here.
60 Chapter 3 Component replacement information and guidelines

HP Z640 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	8 DIMM slots
Form Factor	Tower
Processor Options	Intel Xeon E5-2600 v3/v4
Storage Options	SATA, SAS, SSD
Storage Controllers	Integrated SATA 6.0 Gb/s controller
Graphics Options	NVIDIA Quadro, AMD FirePro
Expansion Slots	1 PCIe Gen3 x8; 1 PCIe Gen3 x4; 1 PCI
Audio	Integrated Realtek HD ALC221
Networking	Integrated Intel I218LM PCIe GbE
Operating Systems	Windows 10
