HP Z640 Workstation system cabling
See
HP Z640 Workstation system board components on page 11 to determine the location of system board
connectors.
Cable To Cable/system board designator
PSU cable PCA P1(PWR) P1
PSU cable PCA P2(PWRMEM) P2
PSU cable First hard drive HDD BAY 0
PSU cable Second hard drive HDD BAY 1
PSU cable Third hard drive HDD BAY 2
PSU cable First optical drive D1
PSU cable Second optical drive D2
PSU cable First graphic card G1
PSU cable Second graphic card G2
Speaker PCA Pre-connected to FUI cable
CPU 0 HS fan cable PCA P8 (CPU 0 FAN) white
Rear fans cable PCA P11 (REAR FANS) white
MB memory fan cable PCA P91(MEM FAN) black blind-mate
Front fan cable PCA P9 (FRNTFAN) white
Front audio cable * PCA P28 (FRONT AUDIO) black
Front USB3.0 cable PCA P29 (FRNT USB3) blue
Front USB2.0 cable PCA P27 (FRNT USB2) yellow
Front UI cable PCA P5(PB/LED) black
Front 1394 cable PCA J12 (1394) white
Media card reader PCA P24 (I-USB2.0) blue
SAS card LED cable PCA P127 black
eSATA external connection PCA P64 (SATA4) black, P65 (SATA5) black
Hood lock cable PCA P124 (HOOD_LOCK) black
Hood sensor cable PCA P2 on FUI Cable, white
Serial option cable PCA P52 (COM) black
Second processor memory fan
cable
Riser PCA P9 (MEM_FAN) black blind-mate
* If an audio card is installed, connect the front audio cable to the audio card connector.
74 Chapter 3 Component replacement information and guidelines
