Requires 2nd
processor
Load
order
Card description Type
Slot
0(Mech
only)
Slot
1(PCI
e3
x8)
Slot
2(PCI
e3
x16)
Slot
3(PCIe
3 x8)
Slot
4(PCIe
3 x16)
Slot 5(PCIe2
x8) (PCIe3 x8
[2nd CPU])
Slot 6
(PCIe3
x16)
Slot 7
(PCIe
2 x1)
8
8 port RAID LSI
9270-8i SAS 6Gb/s
PCIe-x8 2nd 5th 4th 3rd
1st
3
9
Z Turbo Drive 1st
card (M.2)
PCIe-x4 1st 3rd 2nd
10
Z Turbo Drive 2nd
card (M.2)
PCIe-x4 2nd 1st
11
PCIe 1394b card PCIe-x1
Only
6
12
PCIe Network
(LAN)
PCIe-x1;
x4;x8
1st 4th 5th 2nd 3rd
13
eSATA bulkhead
kit
N/A 1st 2nd
14
MiniSAS-4x Cable
(PCI Bulkhead)
N/A Only
15
MiniSAS- 4x Cable
(Chassis Panel
Opening)
N/A See
note
4
* Slots 3 and 4 require second processor.
1: If two Tesla cards are installed, place the first Tesla card in Slot #6 and the second Tesla card in Slot #2 so both are on
CPU0. Place the first graphics card in Slot #4.
2: If a second graphics card is used with a Tesla card, place the Tesla card in Slot #6 and the second graphics in the alternate
slot(s).
3: If an LSI RAID card is being used with a Tesla card or second graphics card, place the Tesla/graphics card in Slot #6 and
the RAID card in Slot 1.
4: Install this panel cable kit in the back panel opening found above slot 7.
5: If 2nd CPU configuration with Thunderbolt card, move E3 jumper to rear pins.
6: 1394 card is not supported in Slot 7 if double wide card loaded in Slot 6.
NOTE: Slot sequenced from the rear I/O aperture to the board edge.
58 Chapter 3 Component replacement information and guidelines
