HP Z640 Workstation Series Service Manual

Problem Cause Possible Solution
2. Repeat this process until the faulty device is identified.
Remove the graphics card last. Replace the faulty device.
3. If no faulty device is found, replace the system board.
OR
1. Press and hold the power button for less than four
seconds. If the hard drive LED does not illuminate:
a. Verify that the computer is plugged into a working
AC outlet.
b. Verify that the power button harness is connected
to the inline front panel I/O device assembly
connector.
2. Verify that the power supply unit (PSU) cables are
connected to the system board.
3. Verify power supply unit PSU functionality:
a. Disconnect the AC power.
b. HP Z840 Workstation only—Remove PSU. All other
workstations, unplug cables connected to the
system board.
c. Reconnect AC power
●
If the PSU fan spins and the BIST LED
illuminates, the PSU is good; replace the
system board.
●
If the PSU fan does not spin or the LED does
not illuminate, replace the PSU.
Troubleshooting scenarios and solutions 83

HP Z640 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	8 DIMM slots
Form Factor	Tower
Processor Options	Intel Xeon E5-2600 v3/v4
Storage Options	SATA, SAS, SSD
Storage Controllers	Integrated SATA 6.0 Gb/s controller
Graphics Options	NVIDIA Quadro, AMD FirePro
Expansion Slots	1 PCIe Gen3 x8; 1 PCIe Gen3 x4; 1 PCI
Audio	Integrated Realtek HD ALC221
Networking	Integrated Intel I218LM PCIe GbE
Operating Systems	Windows 10
