Installing the cable management arm
Procedure
•
NOTE:
◦ If installing the cable management arm on the left, it can be installed as is from the kit. Go to the next
step.
◦ If installing the cable management arm on the right, perform the following step to prepare the cable
management arm.
•
NOTE: For the following step, the orientation and installation of the bracket and screws on the cable
management arm is the same for both sides.
36 Installing the cable management arm
