11. Install the riser cage.
12. Install the system board module.
13. Connect all peripheral cables to the server.
14. Power up the server (Power up the server on page 20).
Installing NVMe drives
Prerequisites
NVMe drives are supported when the NVMe enablement kit is installed. For more information, see Installing
the NVMe enablement kit on page 45.
Before installing this option, be sure that you have the following:
The components included with the hardware option kit
Procedure
1. Observe the following alert:
CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all
bays are populated with either a component or a blank.
2. Remove the drive blank, if installed.
3. Press the Do Not Remove button to open the release handle.
Installing NVMe drives 47
