CAUTION: Be sure to keep the product parallel to the floor when installing the chassis. Tilting the
product up or down could result in damage to the slides.
Procedure
WARNING: On both sides, align the three alignment pins on the chassis with the channel in the rails.
Otherwise, the chassiscan fall if the rack is moved or shipped.
Multiple chassis installed in a rack
When installing multiple chassis in a standard rack, be sure that the cable management arms are installed in
alternating positions.
38 Multiple chassis installed in a rack
