• Extended overload
• Over temperature
• Output short
• Hardware failure
Configuring the UPS
Use the UPS front panel controls to configure the UPS.
IMPORTANT: The output voltage of the UPS must be set to the same nominal voltage as the facility
input. Failure to do so will cause the UPS to buck or boost constantly to maintain the output voltage.
Changing the language
Procedure
1. Press the Enter button to activate the menu options.
2. Press the down arrow button until the Settings menu appears on the LCD menu screen.
3. Press the Enter button.
4. Press the down arrow button until the Local settings menu appears on the LCD menu screen.
5. Press the Enter button.
6. Press the down arrow button until the Language menu appears on the LCD menu screen.
7. Press the Enter button.
8. Press and hold the Enter button to change the language on the UPS.
Changing display functions
The control panel automatically dims after a long period of inactivity. Press any button to restore the screen.
Press the Enter button to activate the menu options. Use the up and down arrow buttons to scroll through the
menu structure. Press the Enter button to enter a submenu or to select an option. Press the ESC button to
cancel or return to the previous menu.
Menu map for display functions
Main menu Submenu Display information or menu function
Measurements — Load, Input/Bypass voltage, Output/Efficiency voltage, Battery
percentage, Average power usage, Cumulative power usage
Control Go to Bypass Transfers the UPS on Bypass mode
Start battery test Starts a manual battery test
Reset fault state Clears active fault
Restore factory
set
Returns all settings to original values
Table Continued
26 Operations
