Item Indicator Status Description
1 Online mode On The UPS is operating normally online or in high efficiency
mode.
2 Battery mode On The UPS is on battery mode.
3 Bypass mode On The UPS is in bypass mode.
4 Fault On The UPS has an active alarm or fault. For more
information, see the Troubleshooting section.
Rear panel components
Figure 1: G2 R5000 4 out NA/JPN model
Figure 2: G2 R5000 5 out NA/JPN model
Component identification 7
