Cable part numberCable part number ColorColor FromFrom ToTo
P01366-B21 Orange Energy pack connector Energy pack
Storage controller backup cablingStorage controller backup cabling
The exact route of the storage controller backup power cabling will depend on:
The riser slot where the controller is installed
The location of the storage controller backup power connector on the controller
Use the following diagrams for reference only.
