SAS
Table 4: LTO-4, LTO-5, and LTO-6 SAS tape drive back panels
1. Tape drive Ethernet port
2. SAS port A
3. SAS port B (LTO-6)
4. Tape drive power LED,
green
Table 5: LTO-7 and LTO-8 SAS tape drive back panels
1. Tape drive Ethernet port
2. SAS port A
3. SAS port B
4. Tape drive power LED,
green
Library user interfaces
The library has two user interfaces:
• Operator control panel (OCP). From the OCP you can operate the library from the front panel.
• Remote management interface (RMI). From the RMI you can monitor and control the library from a
web browser. You can access most library functions from the RMI.
The OCP
The OCP has a power button, four LEDs, four control keys, and a 2-line by 16-character LCD screen.
With the OCP, you can monitor, configure, and operate most library functions from the front panel.
OCP LED indicators
The OCP has four LEDs that provide information.
6 Library user interfaces
