MINIKEY User Manual Change print settings
Page 44 of 66 HSA SYSTEMS
Offset
Head offset is only relevant if you have more than one head on your system. If this is
head one, offset must be set to zero.
If this is head two, offset is the distance from the the first nozzle row of the first pen in
the first head to the first nozzle row of the first pen in the second head.
Upside Down
This option will mirror the image horizontally. Select this option if you are printing "up"
instead of down.
Typically you will want to ENABLE this on web printing, if the latch is facing the
operator.
Other side
This option will mirror the image vertically. Select this option if the head is printing
from the other side of the conveyor.
Mirrored
This option will make the head print in reverse (mirror). Use this option if the print
media is transparent, like f.ex a web or clear plastic.
Pen Voltage and Fire pulse width
These settings can greatly influence the quality of your printout. Please refer to
settings in the Quick start manual.
Ink drop size (pL)
For calculation of low ink level, enter drop size for ink selected.
Pulse Warming
Use warming program for the ink, if required. Can greatly increase the performance of
certain inks. See ink instructions.
Setting up the pen
Select a pen to enter the pen setup menu. The number of pens displayed depends on
the head size. It will be from 1 or 2. The settings may be different for each pen.
