HSD SM 137 D - Setting the RS-485 Address

5 Installation and commissioning
HSD S.p.A. © - h0104k01a.fm291119
45
Setting the RS-485 address
Switches 1 - 5 (DSW2) set the servo-motor RS-485 address. In particular, switch 5 corresponds to the
most significant address bit (A4), and switch 1 corresponds to the least significant address bit (A0).
All 32 combinations between 0 and 31 are allowed.
The table below is given as an example with some address settings.
Examples:
Two devices on the same Fieldbus line cannot have the same address.
DSW2
Switch 12345678910
Address A0 A1 A2 A3 A4 - - - - -
ADDRESS DIP-SWITCH SETTING (from 5 to 1 DSW2)
Decimal Binary A4 A3 A2 A1 A0
01 00001 OFF OFF OFF OFF ON
05 00101 OFF OFF ON OFF ON
10 01010 OFF ON OFF ON OFF
21 10101 ON OFF ON OFF ON
10
9
8
7
6
5
4
3
2
1
10
9
8
7
6
5
4
3
2
1
DSW2
Decimal: 05
like the
example in the
table below
