HSD SM 137 D - Technical Characteristics; Electrical and Mechanical Specifications

A Technical characteristics
HSD S.p.A. © - h0124k00a.fm291119
55
A Technical characteristics
The following tables show the technical product data.
A.1 General data
ELECTRICAL CHARACTERISTICS unit Value
Logic power
Logic supply voltage (Logic V DC)
Safety supply source ±15% (SELV or PELV)
V
DC
24
Max. current absorbed by the logic (Logic V DC) mA 100
Power supply*
*
The sizes are measured on the motor shaft at an ambient temperature of 25°C.
Power supply voltage (Power V DC)
Safety supply source ±10% (SELV or PELV)
V
DC
24
Max. power absorbed by the power
W
430
Power absorbed by the power (S1** 4000 rpm)
**
Refer to the chart in “S1 continuous service”.
135
Power absorbed by the power (S1**0 rpm) 30
Number of poles no. 8
Rated torque Nm 0.25
Rated current A 5.8
Maximum current (SM137D mode) A 15,55
Maximum current
(mode compatible with SM137C and SM137B)
A11.3
Nominal power (Ta=25°C) W 100
Nominal power (Ta=40°C) W 75
Moment of inertia kg*cm
2
0,032324
Voltage constant at Ta=25° V/krpm 2,95
Efficiency % 70
Thermal insulation class (IEC 60034-1) F
