Technical data HTC 950 RX
42 1.0
8 Technical data
The table below shows the machine’s technical data.
HTC 950
RX EU
HTC 950 RX
EU Mist
HTC 950
RX US
HTC 950
RX US Mist
Motor 15 kW 15 kW 15 kW 15 kW
Current 32 A 32 A 32 A 32 A
Tension 3 x 380-415
V
3 x 380-415
V
3 x 440-480
V
3 x 440-480
V
LEDs 24 V 24 V 24 V 24 V
Control current 24 V 24 V 24 V 24 V
Total machine weight 617 kg 622 kg 617 kg 622 kg
Chassis weight 313 kg 318 kg 313 kg 318 kg
Weight, grinding head 304 kg 304 kg 304 kg 304 kg
Weights 2 x 50 kg 2 x 50 kg 2 x 50 kg 2 x 50 kg
Grinding diameter 920 mm 920 mm 920 mm 920 mm
Grinding pressure, weights lowered forwards 362 kg 362 kg 362 kg 362 kg
Grinding pressure, weights in the up position 251 kg 251 kg 251 kg 251 kg
Grinding pressure, weights folded backwards 195 kg 195 kg 195 kg 195 kg
RPM 458 - 1374
r.p.m
458 - 1374
r.p.m
458 - 1374
r.p.m
458 - 1374
r.p.m
Water tank 10 litres 10 litres 10 litres 10 litres
Grinding discs 4 x 270 mm 4 x 270 mm 4 x 270 mm 4 x 270 mm
Recommended minimum cable area 6 mm² 6 mm² 6 mm² 6 mm²
Sound pressure level, average value over time
according to ISO 3741, measurement
uncertainty according to class 1 measuring
instruments for sound level meters.
92 dBA 92 dBA 92 dBA 92 dBA
