HTP Elite FT Series User Manual

LP-387 Rev. 011 Rel. 005 Date 1.3.19
29
B. Approved Materials for Exhaust Vent and Intake Pipe
Table 9 - Approved Materials for Exhaust Vent and Intake Pipe
C. Additional Requirements for Installation in Canada
1. Installations must be made with a vent pipe system certied to
ULC-S636. IPEX is an approved vent manufacturer in Canada supplying
vent material listed to ULC-S636. Additionally, you may use AL29-4C
stainless steel venting to comply with Canadian requirements.
2. The rst three (3) feet of vent pipe from the boiler ue outlet must be
readily accessible for visual inspection.
3. The components of the certied vent system must not be
interchanged with other vent systems or unlisted pipe / ttings.
DO NOT mix components from dierent venting systems without
proper adapters. The vent system could fail, causing leakage of
ue products into the living space. Use only the approved pipe and
tting materials, and primer and cement specically designed for
the material used, as listed in the above table. Failure to do so could
result in property damage, serious injury, or death.
High heat sources (generating heat 100
o
F / 37
o
C or greater, such
as boiler ue pipes, space heaters, etc.) may damage plastic
components of the boiler as well as plastic vent pipe materials.
Such damages ARE NOT covered by warranty. It is recommended
to keep a minimum clearance of 8” from high heat sources.
Observe heat source manufacturer instructions, as well as local,
state, provincial, and national codes, laws, regulations, and
ordinances when installing this boiler and related components
near high heat sources.
NOTE: The use of double-wall vent or insulated material for the
combustion air intake pipe is recommended in cold climates to
prevent the condensation of airborne moisture in the incoming
combustion air.
You must not use “B” vent in an exhaust application. “B” vent is for
intake applications ONLY. Using “B” vent in an exhaust application
will result in serious injury or death.
• The exhaust and intake components installed with this appliance must be used for near appliance piping BEFORE transitioning to
the approved materials listed above. DO NOT REMOVE these installed components. Doing so WILL VOID appliance warranty.
• PVC / CPVC pipe and ttings of the same diameter are considered interchangeable.
• The use of cellular core PVC (ASTM F891), cellular core CPVC, or Radel
®
(polyphenolsulfone) in non-metallic venting systems is
prohibited.
• Covering non-metallic vent pipe and ttings with thermal insulation is prohibited.
• DO NOT connect PVC/CPVC to Polypropylene without an approved vent connector.
• Any transition to Polypropylene MUST be done in the vertical within ve (5) feet of the appliance.
• When installing AL29-4C vent piping, install a PVC-to-stainless adapter at the appliance vent connection, and at the termination
when using a PVC termination kit. DO NOT mix AL29-4C piping from dierent manufacturers unless using adapters specically
designed for the purpose by the manufacturer.
• A double wall vent or insulated material may be used when using stainless steel vent material in a freezing climate.
• *ABS may be used for air intake applications ONLY. ABS is NOT PERMITTED for use in Canada.
• Contact the venting material manufacturer if there is any question about the applicability of the proposed venting material.
Failure to follow these directions will result in substantial property damage, severe personal injury, or death.
Item Material
Standards for Installation In:
United States Canada
Pipe and Fittings Approved for Intake ONLY ABS* ANSI/ASTM D2661 NOT PERMITTED
Pipe Approved for
Intake OR Exhaust Vent
PVC Schedule 40/80 ANSI/ASTM D1785
PVC, CPVC, and PP Venting
Must be ULC-S636 Certied.
IPEX is an approved
manufacturer in Canada.
PVC-DWV Schedule 40/80 ANSI/ASTM D2665
CPVC Schedule 40/80 ANSI/ASTM F441
Polypropylene UL-1738 or ULC-S636
Stainless Steel AL29-4C Certied for Category IV and Direct Vent Appliance Venting
Pipe Fittings
PVC Schedule 40 ANSI/ASTM D2466 or D2665
PVC, CPVC, and PP Venting
Must be ULC-S636 Certied.
IPEX is an approved
manufacturer in Canada.
PVC Schedule 80 ANSI/ASTM D2467 or D2665
CPVC Schedule 40 ANSI/ASTM F438
CPVC Schedule 80 ANSI/ASTM F439
Pipe Cement
ABS* ANSI/ASTM D2235 NOT PERMITTED
PVC ANSI/ASTM D2564
IPEX System 636 Cements
and Primers
CPVC ANSI/ASTM F493
Pipe Primer PVC / CPVC ASTM F656
