85
86
LP-532 REV. 8.13.2014
LP-532 REV. 8.13.2014
Main components Replacement Instructions
10.ColdWaterInletFilter 11.MixingValve
1.Closethegasshuto󰘯valve
2.Turnthepowero󰘯
3.Closeallwatervalvesanddrainwaterfromunit.
4.Placeabucketundertheappliancetocollectthe
residualwaterinsidethewaterheater.
5.Separatecoldwaterinlet󰘰lterbyrotatingcounter-
clockwise.
6.Cleanitwithasmallbrushandcleanrunning
water.
7.Openthegasshuto󰘯valve
8.Turnthepoweron
9.Openallwatervalves.
10.Turntheunitonandensureproperoperation.
1.Closethegasshuto󰘯valve
2.Turnthepowero󰘯
3.Closeallwatervalvesanddrainwaterfromunit.
4.Loosentwoscrewstoaccesscontroller
connections
5.Separateconnectorconnectedwithmixingvalve.
6.Removetwoclipsconnectedwithmixingvalve
andoutletpipe.
7.Separatemixingvalveandoutletpipe
8.Removemixingvalveandreplacewithnewcomponent.
9.Assemblyisinthereverseorderasthepartwas
repaired.
10.Openthegasshuto󰘯valve
11.Turnthepoweron
12.Openallwatervalves.
13.Turntheunitonandensureproperoperation.
Chapter 5 Replacement instructions
Main components Replacement Instructions
12.AirGasMixer(AGM)
1.Closethegasshuto󰘯valve
2.Turnthepowero󰘯
3.SeparateintakepipeattachedtoAGM.
4.RemoveAGMconnector.
5.Removefanconnector.
6.LoosengaspipenutconnectedwithAGM
7.Loosenburnerplatebracket’sbyloosentwo
screwsasshown.
8.LoosentwoscrewstoremoveAGM
9.ReplaceAGMwithnewcomponent
10.Assemblyisinthereverseorderasthepartwas
repaired.
11.Openthegasshuto󰘯valve
12.Turnthepoweron
13.Openallwatervalves.
14.Turntheunitonandensureproperoperation.
Chapter 5 Replacement instructions
WARNING
Failure to turn the power o to the appliance
before repair could result in serious injury or
death.
WARNING
Failure to wait for appliance to cool before
continuing with repair could result in serious
injury or death.
WARNING
Failure to turn the power o to the appliance
before repair could result in serious injury or
death.
WARNING
Failure to wait for appliance to cool before
continuing with repair could result in serious
injury or death.
WARNING
Failure to turn the power and gas o to the
appliance before repair could result in serious
injury or death.
