2.1 Product Introduction
This topic provides the appearance and describes the ports and LEDs of the HG861.
HG861 is an indoor optical network terminal (ONT) at the gigabit-capable passive optical
network (GPON) user access layer, designed for home users and SOHO users. Adopting the
GPON technology, the HG861 connects the home users and SOHO users to the Internet through
the optical upstream port.
On the local area network (LAN) side, the HG861 provides abundant hardware ports to meet
multiple networking requirements of home users and SOHO users.
The HG861 supports the ONT management and control interface (OMCI) technology, which
facilitates the automatic service provision remotely by service providers, and the remote
maintenance and management by network maintenance staff.
2.1.1 Appearance
This topic provides the appearance of the HG861.
2.1.2 Ports
This topic provides the port appearance of the HG861 and describes the functions of the ports.
2.1.3 LEDs
This topic provides the LED appearance and describes the indications of the LEDs on the
HG861.
2.1.1 Appearance
This topic provides the appearance of the HG861.
Figure 2-1 shows the appearance of the HG861.
Figure 2-1 Appearance of the HG861
2 System Overview EchoLife HG861 GPON Terminal
2-2 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2009-07-30)
