Huawei EchoLife HG861 - Connecting Cables; Figure 2-6 Connections of the HG861

----End
2.3.2 Connecting Cables
This topic describes how to connect cables for the ports on the HG861.
Prerequisite
CAUTION
Before connecting the cables, disconnect the power supply of all the devices to be connected to
the HG861, such as the PC and IP STB.
Context
Figure 2-6 shows the connections of the HG861.
Figure 2-6 Connections of the HG861
