Huawei EchoLife HG861 User Manual

Table 2-2 and Table 2-3 describe the LEDs on the HG861.
Table 2-2 Indications of the LEDs on the HG861
LED Name Status Description
POWER
Power supply
LED
On The HG861 is powered on.
Off The HG861 is powered off.
CATV
Cable television
LED
On
The CATV function is enabled, and
the CATV optical signal is
detected.
Off
The CATV function is not enabled,
or the CATV function is enabled
but the CATV optical signal is not
detected.
LINK
Connection
LED
See Table 2-3 See Table 2-3
AUTH
Authentication
LED
See Table 2-3 See Table 2-3
LAN
Ethernet port
LED
On
The connection on the Ethernet port
is normal.
Off
No connection is set up on the
Ethernet port.
Blinks
Data is being transmitted on the
Ethernet port.
Table 2-3 Status of the LINK LED and the AUTH LED
No.
LED Status
Description
LINK AUTH
1 Off Off
The HG861 is in the
initiation state.
2 Blinks (slow) Off The HG861 is ready.
3 Blinks (quickly) Blinks (slow)
The HG861 is in the SN
authentication state.
4 Blinks (quickly) On
The HG861 is in the
ranging state.
5 On On
The HG861 is in the
operation state (normal
working state).
2 System Overview EchoLife HG861 GPON Terminal
2-4 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2009-07-30)
