3.2.3 Collecting the Fault Information
When the GPON service is faulty, you need to collect the fault information through the NMS.
Procedure
Step 1 On the Physical Map navigation tree on the Main Topology tab page, double-click the required
OLT; or select the required OLT, right-click, and then choose Device Management.
Step 2 Choose Device Panel from the navigation tree on the tab page that is displayed.
Step 3 Enter the shelf interface, and select the board to be queried. Click the tab page in the lower part
of the interface to query detailed board information.
Step 4 Choose GPON > GPON ONU.
Step 5 On the GPON ONU tab page, set the querying criteria to display the required GPON ONUs.
Step 6 Select a record from the ONU list, and check the version and LED status of the ONT.
NOTE
The NMS version is R12C03.
----End
3.3 Command Lines
Before maintaining the HG861, make sure that you have mastered the usage of command lines,
which is a means to configure the device.
3.3.1 Command Introduction
This topic describes the structure and the modes of commands.
3.3.2 Common Commands
3.3.1 Command Introduction
This topic describes the structure and the modes of commands.
l Command Structure
The command prompt consists of two parts: fixed character string and command mode
identifier.
Use "HG861>" for example. "HG861" is the fixed character string used for identifying the
device that is logged in to. ">" is the command mode identifier used for identifying the
current mode.
l Command Modes
The command modes of the HG861 consist of user mode, privilege mode, and global config
mode.
Figure 3-1 shows the relations between the command modes. A pane represents a command
mode. An arrow indicates the switching from one mode to another mode. The switching
commands are listed near the arrows.
3 Configuration Guide EchoLife HG861 GPON Terminal
3-4 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2009-07-30)
