FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
3 System Architecture
Issue 01 (2017-04-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
36
Item
Specifications
Dynamic load
1000 kg
Weight
128 kg (excluding batteries)
Protection level
IP20
Table 3-16 lists the number of batteries with different capacity a single battery cabinet can
house.
Shoto and Enersys batteries are supported.
Table 3-16 Maximum number of batteries inside a single battery cabinet
Battery Specifications
Maximum Number of Batteries
Inside a Single Battery Cabinet
26 Ah
20
40 Ah
20
65 Ah
20
100 Ah
20
Table 3-17 Configuration scenarios (for both the main and auxiliary battery cabinets)
Battery Specifications
Layer (from Top to Bottom)
Number of
Batteries
26 Ah/40 Ah
Layer 1
10
Layer 2
10
Layer 3
N/A
Layer 4
N/A
65 Ah/100 Ah
Layer 1
5
Layer 2
5
Layer 3
5
Layer 4
5
