Sensor Description Component
CPU
N
VRD Temp CPU VRD temperature CPU 1: Component in
position U4316 on the
mainboard.
CPU 2: Component in
position U4322 on the
mainboard.
CPU 3: Component in
position U4370 on the
mainboard.
CPU 4: Component in
position U4377 on the
mainboard.
N
indicates the CPU
number. The value
ranges from 1 to 4.
CPU
N
MEM Temp CPU DIMM temperature DIMMs of CPU
N
.
N
indicates the CPU
number. The value
ranges from 1 to 4.
SSD Disk
N
Temp SSD temperature SSD.
N
indicates the
physical drive slot
number.
FAN
N
F Speed Fan speed sensor Fan module.
N
indicates
the fan module number.
The value ranges from 1
to 4.
FAN
N
R Speed
Power Server input power Total PSU power.
Power
N
PSU input power PSU.
N
indicates the PSU
number. The value is 1 or
2.
CPU
N
Status CPU status CPU.
N
indicates the CPU
number. The value
ranges from 1 to 4.
CPU
N
Memory DIMM status DIMM corresponding to
the CPU.
N
indicates the
DIMM number. The
value ranges from 1 to 4.
PS
N
Fan Status PSU fan status PSU.
N
indicates the PSU
number. The value is 1 or
2.
PS
N
Temp Status PSU presence
PS
N
Status PSU status
Power Button Power button Right mounting ear
Huawei FusionServer Pro 2488 V5 Server
Technical White Paper A Appendix
Issue 11 (2020-09-03) Copyright © Huawei Technologies Co., Ltd. 65
