Sensor Description Component
UID Button UID button status
DISK
N
Drive status Drive.
N
indicates the
physical drive slot
number.
FAN
N
F Presence Fan presence Fan module.
N
indicates
the fan module number.
The value ranges from 1
to 4.
FAN
N
R Presence
FAN
N
F Status Fan status
FAN
N
R Status
RTC Battery RTC battery status. An
alarm is generated when
the voltage is lower than
1 V.
CMOS battery
DIMM
N
DIMM status DIMM.
N
indicates the
DIMM slot number.
PS
N
Inlet Temp PSU air inlet
temperature
PSU.
N
indicates the PSU
number. The value is 1 or
2.
PCH Status PCH chip fault diagnosis
health status
Component in position
U4014 on the
mainboard.
LCD Presence LCD presence LCD
LCD Status LCD health status
PS
N
Redundancy Redundancy failure due
to PSU removal
PSU.
N
indicates the PSU
number. The value is 1 or
2.
BMC Boot Up BMC startup events N/A
N
indicates the number
of the component.
SEL Status SEL full or clearing
events
Op. Log Full Operation log full or
clearing events
Sec. Log Full Security log full or
clearing events
CPU Usage CPU usage
Memory Usage Memory usage
PCIe
N
Card BBU BBU fault or low voltage
on a plug-in PCIe RAID
controller card
Huawei FusionServer Pro 2488 V5 Server
Technical White Paper A Appendix
Issue 11 (2020-09-03) Copyright © Huawei Technologies Co., Ltd. 66
