Version 2.1 (May 2016) 13
2.2.2. ISDN Line and 3G/4G connection
Connect your devices in the sequence indicated in the following figure.
Picture 2-2 connect devices in hybrid broadband network
(ISDN Line)
1 HA35 2 Telephone wall jack 3 Splitter
4 SIM card 5 Telephone 6 ISDN (NT1) Device
7 Desktop computer 8 Set-top Box 9 Power adapter
10
Laptop computer 11
Smart Phone 12 Pad
a LINE port b PHONE port c MODEM port
When configuring the HA35 for the first time, use an Ethernet cable to connect the HA35
to a computer.
