Installation Manual
Quidway Eudemon200 Firewall Chapter 1 Overview
1-8
Table 1-3 Console interface attributes
Attribute Description
Connector
RJ-45
Interface standard
EIA/TIA-232
Baud rate
9600bps - 115200bps
9600bps by default
Supported service
Connect to the ASCII terminal
Connect to the serial interface of the local PC and run terminal emulation program on the
PC
Command Line Interface (CLI)
2) AUX interface
Table 1-4 AUX interface attributes
Attribute Description
Connector RJ-45
Interface standard EIA/TIA-232
Baud rate 300 ~ 115200bps
Supported service
Modem dialup
Backup
Serve as console port, when the console port fails.
Supported protocol PPP
3) Ethernet interface
The RPU provides two 10/100Base-TX Ethernet ports on its panel (Ethernet 0/0/0 at
left and Ethernet 0/0/1 at right). Their attributes are listed in the following table.
