7.8.2 Interface Attributes
Table 7-12 Interface attributes of the ATM modules
Attribute 1ATM-OC3MM 1ATM-OC3SM 1ATM-OC3SML
Optical fiber
connector
SC
Connector
number
1
Interface standard SONET OC-3/SDH STM-1
Interface speed 155Mbps
Cable and the
max. transmission
distance
Multi-mode optical
fiber of 2km
transmission distance
Single-mode optical
fiber of 15km
transmission distance
Single-mode optical
fiber of 30km
transmission distance
Transmitter LED LD LD
Transmitting
optical power
Min: -15dBm
Max: -8dBm
Min: -19dBm
Max: -14dBm
Min: -5dBm
Max: 0dBm
Receiver
sensitivity
Min: -28dBm
Max: -8dBm
Min: -30dBm
Max: -14dBm
Min: -34dBm
Max: -10dBm
Central
wavelength
1310nm
Supported service ATM Traffic CBR (Constant Bit Rate), rt_VBR (Variable Bit Rate-Real Time),
nrt_VBR (Variable Bit Rate-Non Real Time), UBR (Unspecified Bit Rate)
Supported
protocol
AAL5
IPOA
PPPOA
RFC 1483 (PPPoEoA and IPoEoA)
F5 END TO END LOOPBACK OAM
7.8.3 Panel and Interface LED
Table 7-13 illustrates the 1ATM-OC3MM/1ATM-OC3SM/1ATM-OC3SML panels and
LEDs description.
