Huawei Quidway Eudemon 200 - Ethernet Cable Pinouts

Installation Manual
Quidway Eudemon 200 Firewall Appendix A Specifications of Interface Cables
A-3
Pair 1
Blue
White/Blue
Pair 2
Orange
White/Orange
Pair 3
Green
White/Green
Pair 4
Brown
White/Brown
Figure A-2 Category 5 twisted pair
A.3.3 Ethernet Cable Pinouts
Table A-3 Straight -through cable pinouts
RJ45 Signal
Category 5
Twisted Pair
Signal Direction RJ45
1 TX+ White (Orange)

1
2 TX- Orange

2
3 RX+ White (Green)

3
4 - Blue - 4
5 - White (Blue) - 5
6 RX- Green

6
7 - White (Brown) - 7
8 - Brown - 8
Table A-4 Crossover cable pinouts
RJ45
Signal
Direction
Category 5
Twisted Pair
Signal Direction RJ45
1 TX+ White (Orange)

3
2 TX- Orange

6
3 RX+ White (Green)

1
4 - Blue - 4
5 - White (Blue) - 5
6 RX- Green

2
