Quidway Eudemon 200 Firewall Appendix A Specifications of Interface Cables
A-1
Appendix A Specifications of Interface Cables
 Note:
The pinouts not described in the following tables of this appendix are not connected.
A.1 Console Cable
Table A-1 Console cable pinouts
RJ45
Signal
Direction
DB25 DB9 Signal
1

5 8 CTS
2

6 6 DSR
3

3 2 RXD
4

8 1 DCD
5
-
7 5 GND
6

2 3 TXD
7

20 4 DTR
8

4 7 RTS
A.2 AUX Cable
Table A-2 AUX cable pinouts
RJ45
Signal
Direction
DB25 DB9 Signal
1

4 7 RTS
2

20 4 DTR
3

2 3 TXD
4

8 1 DCD
5
-
7 5 GND
