Installation Manual
Quidway S3900 Series Ethernet Switches Chapter 5 Loading Boot ROM and Host Software
Huawei Technologies Proprietary
5-7
Step 2: Enter <3> in the loading menu to download through XModem. The system
displays the following download speed setting menu:
Please select your download baudrate:
1.* 9600
2. 19200
3. 38400
4. 57600
5. 115200
0. Return
Enter your choice (0-5):
Step 3: Choose an appropriate download baud rate. Enter <5> for example to
download at 115200 bps. The system displays the following information:
Download baudrate is 115200 bps
Please change the terminal's baudrate to 115200 bps and select XMODEM protocol
Press enter key when ready
Note:
You do not need to modify the HyperTerminal’s baud rate if you have chosen 9600 bps,
and thus can skip Steps 4 through 6 and proceed to Step 7 directly. At this time, the
system does not display the above information.
Step 4: Enter HyperTerminal’s [File/Properties] menu, as shown in Figure 5-1. Click
<Configuration> in the popup dialog box, select the baud rate of 115200bps in the
Console Port Configuration dialog box, as shown in Figure 5-2.
