HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
Hardware and Software Compatibility
Table 1-3 lists the boards that can be used in F8002 subracks.
Table 1-3 Types of boards in the F8002 subrack
MXU Type
Compatible Service
Board Type
Compatibility Rule
MXU

SPU

VPU
-
Technical Specifications
Table 1-4 lists the technical specifications of the F8002 subrack.
Table 1-4 F8002 subrack technical specifications
Item
Specifications
Mechanical
specificatio
ns
Dimensions (H x W x D)
130.5 mm x 442.0 mm x 675.0 mm (5.14 in. x
17.40 in. x 26.57 in.)
Weight of an empty
subrack
20.8 kg (45.86 lb)
NOTE
An empty subrack is equipped with two fan trays
and two PEMs.
Weight of a fully loaded
subrack
47.8 kg (105.38 lb)
NOTE
A fully loaded subrack is equipped with two fan
trays, two PEMs, two MXUA0s, and four SPUA0s.
Power
supply
Rated input voltage
-48 V DC to -60 V DC
Operating voltage
-40 V DC to -72 V DC
Total power inputs
Two
Rated input current
60 A/power input
Power rating
2400 W (The rated power of each PEM is
2400 W)
NOTE
The subrack is configured with two PEMs in 1+1
redundancy mode.
Environme
ntal
specificatio
ns
Temperature

Long-term operating temperature: 0°C to
45°C (32°F to 113°F)

Short-term operating temperature: -5°C to
+55°C (23°F to 131°F)

Storage temperature: -40°C to +70°C
(-40°F to +158°F)
