HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
controls the power-on, power-off, hot swap, and reset operations of
the board.
Supports serial port redirection.
Loads board software online.
Provides a loading interface for board testing.
The boards are hot-swappable.
Appearance
The VPUA0s are half-width boards and installed in the front service board slots of the
subrack. Figure 1-52 shows a VPUA0.
Figure 1-52 Appearance (unit: mm)
Figure 1-53 shows the hardware structure of the VPUA0.
