Huawei SUN2000-3KTL-L1 User Manual

Applicable Model Application Scenario
Single inverter + Smart Dongle (WLAN-FE) + LUNA2000
connected to the management system
Parameter Settings
On the home screen, choose Power adjustment > Capacity control and set
capacity control parameters.
NO TE
● The capacity control function is unavailable when the energy storage working mode is
set to Fully fed to grid.
● When capacity control has been enabled, you must
rst disable capacity control and
then set the energy storage working mode to Fully fed to grid.
Figure 7-14 Setting capacity control parameters
Parameter Description Range
Capacity control 1. Before enabling Capacity
control, set Charge from
grid to Enable.
2. Before disabling Charge
from grid, set Capacity
control to Disable.
● Disable
● Active capacity limit
SUN2000-(2KTL-6KTL)-L1
User Manual 7 Man-Machine Interaction
Issue 10 (2023-02-13) Copyright © Huawei Technologies Co., Ltd. 82

Huawei SUN2000-3KTL-L1 Specifications

General

Max. efficiency	98.4%
Max. input voltage	600 V
Nominal output power	3000 W
Dimensions (W x H x D)	365 x 365 x 156 mm
Operating temperature range	-25°C to +60°C
Nominal AC voltage	220 V / 230 V / 240 V
MPPT voltage range	90 V - 560 V
Rated input voltage	360 V
Number of MPPTs	2
Cooling	Natural Convection
Protection degree	IP65
Rated output voltage	220 V / 230 V / 240 V
Output frequency	50 Hz / 60 Hz
Power factor	0.8 leading ... 0.8 lagging
THDi	<3%
Efficiency	98.4%
Warranty	10 years
Max. apparent AC power	3300 VA
Max. output power	3300 W
