Parameter Description Value Range
Maximum charge
power (kW)
Retain this parameter to the
maximum charge power.
Additional conguration is not
required.
Charge: [0,
Maximum charge
power]
Maximum discharge
power (kW)
Retain this parameter to the
maximum discharge power.
Additional conguration is not
required.
Discharge: [0,
Maximum
discharge power]
End-of-charge SOC
(%)
Set the charge cuto capacity. 90%–100%
End-of-discharge
SOC (%)
Set the discharge cuto
capacity.
0%–20% (When no PV
module is congured
or the PV modules
have no voltage for 24
hours, the minimum
value is 15%.)
Charge from grid If Charge from grid function is
disabled by default, comply
with the grid charge
requirements stipulated in local
laws and regulations when this
function is enabled.
Disable
Enable
Grid charge cuto
SOC
Set the grid charge cuto SOC. [20%, 100%]
7.2.1.4 Capacity Control
Prerequisites
The screenshots in this section are captured from the SUN2000 app 6.23.00.125.
The actual screens may vary with app updates.
Description
If the inverter connects to an ESS and the ESS working mode is set to Maximum
self-consumption or TOU, you can set capacity control parameters.
Table 7-3 Application Scenario
Applicable Model
Application Scenario
SUN2000-
(2KTL-6KTL)-L1
Single inverter + LUNA2000 directly connected to the
management system
SUN2000-(2KTL-6KTL)-L1
User Manual 7 Man-Machine Interaction
Issue 10 (2023-02-13) Copyright © Huawei Technologies Co., Ltd. 81

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Huawei SUN2000-3KTL-L1 and is the answer not in the manual?

Huawei SUN2000-3KTL-L1 Specifications

General IconGeneral
Max. efficiency98.4%
Max. input voltage600 V
Nominal output power3000 W
Dimensions (W x H x D)365 x 365 x 156 mm
Operating temperature range-25°C to +60°C
Nominal AC voltage220 V / 230 V / 240 V
MPPT voltage range90 V - 560 V
Rated input voltage360 V
Number of MPPTs2
CoolingNatural Convection
Protection degreeIP65
Rated output voltage220 V / 230 V / 240 V
Output frequency50 Hz / 60 Hz
Power factor0.8 leading ... 0.8 lagging
THDi<3%
Efficiency98.4%
Warranty10 years
Max. apparent AC power3300 VA
Max. output power3300 W
