Huawei SUN2000-3KTL-L1 User Manual

Check Item Check Method Maintenance
Interval
Grounding
reliability
Check that ground cables are securely
connected.
The rst inspection is
6 months after the
initial
commissioning.
From then on, the
interval can be 6 to
12 months.
8.3 Troubleshooting
Alarm severities are
dened as follows:
● Major: The SUN2000 enters the shutdown mode or functions abnormally
after a fault occurs.
● Minor: Some components are faulty but the SUN2000 can still connect to the
power grid and generate power.
● Warning: The SUN2000 functions normally, but its output power decreases
due to external factors.
Table 8-2 Common alarms and troubleshooting measures
Alarm
ID
Alarm Name Alarm
Severity
Possible Causes Troubleshooting
2001 High String
Input Voltage
Major The PV array is not properly
congured. Excessive PV
modules are connected in
series to the PV string, and
therefore the open-circuit
voltage exceeds the
maximum SUN2000
operating voltage.
Cause ID = 1, 2
● 1: The PV1 input voltage
is high.
● 2: The PV2 input voltage
is high.
Check the serial connection
conguration of the PV
string and ensure that the
PV string open-circuit
voltage is not greater than
the maximum operating
voltage of the SUN2000.
After the PV array
conguration is corrected,
the alarm disappears.
2002 DC Arc Fault Major The PV string power cables
arc or are in poor contact.
Cause ID = 1, 2
● 1: PV1 DC arc fault
● 2: PV2 DC arc fault
Check whether the string
cables arc or are in poor
contact.
SUN2000-(2KTL-6KTL)-L1
User Manual 8 System Maintenance
Issue 10 (2023-02-13) Copyright © Huawei Technologies Co., Ltd. 90

Huawei SUN2000-3KTL-L1 Specifications

General

Max. efficiency	98.4%
Max. input voltage	600 V
Nominal output power	3000 W
Dimensions (W x H x D)	365 x 365 x 156 mm
Operating temperature range	-25°C to +60°C
Nominal AC voltage	220 V / 230 V / 240 V
MPPT voltage range	90 V - 560 V
Rated input voltage	360 V
Number of MPPTs	2
Cooling	Natural Convection
Protection degree	IP65
Rated output voltage	220 V / 230 V / 240 V
Output frequency	50 Hz / 60 Hz
Power factor	0.8 leading ... 0.8 lagging
THDi	<3%
Efficiency	98.4%
Warranty	10 years
Max. apparent AC power	3300 VA
Max. output power	3300 W
