SUN2000L-(2KTL-5KTL)
User Manual
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 5-17 Connecting battery cables
----End
5.6 Installing the Signal Cable
Context
When laying out signal cables, separate them from power cables to avoid strong signal
interference sources.
Figure 5-18 COM and ALARM ports
The COM port provides two RS485 communications ports and one enable signal port to
connect to power collectors, batteries, and so on.
