HUBBELL LIGHTING CX - Installation Instructions Overview

3
Introduction
The information in this User Manual is provided as a guide for understanding of the components and the reliable programming
examples for a User. The instructions should be selected based on application and functionality.
Installation Instructions
Programming Instructions
Installation Instructions
The installation instructions consist of the following:
Description
Product Congurations
Enclosure Mounting
Installing individual Relay Cards
Connecting Panel Power
Connecting Lighting Loads
Connecting Low Voltage Inputs
Operating the Panel
Troubleshooting
Panel Specications
Panel Load Schedule Form
Description
CX Commercial Lighting Control Panels – 4, 8, 16 and 24 Relay Panels are shipped in one package. Panels are congured with
all relays of the same type installed or no relays with space only for relays to be installed in the eld. Relays are mounted with
lighting circuit terminals in the high voltage area separated by a metal divider. Low voltage control inputs are located in the low
voltage area of the panel. The following information describes the CX 4, 8, 16 and 24 relay panel installations. For programming
information, refer to the “CX Panel Programming Guide” provided as a separate document with the Panel.
Product Conguration
Example: CX082S08R2NM - CX 8 Relay Panel, 120/208/220/277VAC input, with 8 20A/1P NO Electrically Held Relays
installed in NEMA 1 Surface Mount Master Panel.
Panel
Model
Relay Spaces Input Voltage Housing Relay Quantity Relay Type Options
04 4 Relay Spaces 2 120/208/220-277VAC Multi-Tap 00 No relays 2N 20A, 1P, NO Elect Held N Stand Alone (4-Relay ONLY)
08 8 Relay Spaces 3 120/277/347VAC Tri-Tap 04 4 Relays Installed 3L 30A, 1P, Latching M Master (8 Relay ONLY)
08 8 Relays Installed TN 20A, 2P, NO Elect Held S Secondary (8 Relay ONLY)
TC 20A, 2P, NC Elect Held
SP Space Only
Panel
Model
Relay Spaces Input Voltage Housing Relay Quantity Relay Type Options
16 16 Relay Spaces 2 120-277VAC Universal 00 No relays 2N 20A, 1P, N/O Elect Held M Master
24 24 Relay Spaces 3 347-480VAC Universal 16 16 Relays Installed 3L 30A, 1P, Latching S Secondary
24 24 Relays Installed TN 20A, 2P, N/O Elect Held
TC 20A, 2P, N/C Elect Held
SP Space Only
CX
S Surface
NEMA 1
CX
S Surface
NEMA 1
PART 1 - CX Lighting Control Panels Installation Guide
