HUBBELL LIGHTING CX - Panel Specifications and Connections

8
Troubleshooting
A blinking “green” Relay board status LED indicates that communication has not been properly established for this card.
Contact Hubbell Building Automation Technical Service at (888) 698-3242 for assistance and replacement as required. A
complete Troubleshooting Guide is contained in the “CX Panel Programming Guide” provided as a separate document with the
Panel.
CX Panel Specications
Panel Input Power Requirements:
Input Voltage “2” designator – 40VA, 120/ 208/ 240/277VAC for a CX04 and CX08. 120-277 for a CX16 and CX24
Input Voltage “3” designator – 75VA, 120/277/347VAC for a CX04 and CX08. 247-480VAC for aCX16 and CX24.
Overall Dimensions:
Surface mount CX04-08, 14.5” W x 17” H x 3.5” D
Surface mount CX16-24, 20”W x 24”H x 3.5”D
Relay Load Ratings:
CXR2N – 120/277VAC, Electrically Held, NO, 20Amps, HID, Ballast and Tungsten (120V only), 1HP at 120V, 2HP at
277V, 14KAIC Rated
CXR3L – 120/277/347VAC, Latching, 30Amps, HID, Ballast and 20A mps Tungsten (120V only), 1HP at 120V, 2HP at
277V and 347V, 18KAIC Rated
CXRTN – 208/240/480VAC, Electrically Held, NO, 20Amps, HID, Ballast, 2HP, 14KAIC Rated
CXRTC – 208/240/480VAC, Electrically Held, NC, 20Amps, HID, Ballast, 2HP, 14KAIC Rated
Low Voltage Inputs:
CX04-Relay Panel - 6 available inputs - Maximum 8 low voltage powered devices
CX08-Relay Panel - 12 available inputs - Maximum 8 low voltage powered devices
CX16-Relay Panel - 20 available inputs - Maximum 24 low voltage powered devices
CX24-Relay Panel - 30 available inputs - Maximum 24 low voltage powered devices
Low Voltage Switches:
Momentary or Maintained style, with or without LED indication. LED indication support is LED - “ON” when switch is
active and LED - “OFF” when switch is inactive. Green “ON” with Red “OFF” indication is not supported.
Motion Sensor Input:
Three wire 24 VDC.
Photocell;
Three wire 24VDC power, 0-10V DC control input.
Output Relay Contacts:
Two each for CX08/CX16 - Relay Panels - Dry Contact Output, NO/NC, 24V AC/DC, 50mA
Three for the CX24 – Relay Panel - Dry Contact Output, NO/NC, 24V AC/DC, 50mA
Dimming Control Card:
CX04 and CX08 Relay Panels – Supports 1 Dimming Card each
CX16 Relay Panel – Support 2 Dimming Cards
CX24 Relay Panel – Support 3 Dimming Cards
Each Dimming Card supports 8 low voltage 0-10V dimming channels
Four RJ45 ports per Dimming Card to connect to low voltage switches using CAT5 Cables with RJ45 jacks.
Zone5 Low Voltage Switches:
Z5-SW-MC, to be used for On and Off only functionality
Z5-SW-AVD, to be used for Raise/Lower functionality for 0-10V dimming channels
When using Master/Secondary conguration, only a maximum of 4 Dimming Control Cards can be used to work together.
Operating Environment:
Indoor Use Only; 0 to 50°C; Relative Humidity: 0 - 90% non-condensing.
Panel load schedule form
A Panel Load Schedule Form is supplied in the clear plastic pocket inside the Panel Door to record the lighting circuit relay
assignments while connecting the relays. Low voltage input types and assignments should also be recorded on the form.
