Problems on the Road
. . . 346
Jack and Spare Tire
Removal
The jacking tools are stored under
the rear seat.
To remove the equipment, do the
following:
1. Turn the wing nut counter-
clockwise to release the jack
and tool bag.
2. Remove the jack and tool bag.
If your vehicle has locking
wheel nuts, the key is in the
tool bag.
3. Unfasten the straps holding
the tool bag to the jack.
Remove wheel wrench .
Remove jack handle
extensions .
Remove jack handle .
Remove jack .
Remove wheel blocks .
The spare tire is attached to the
tire carrier underneath the vehicle.
A B C D E
