Section 1
3. Slide the lower end fitting
onto the front bolt. The tail-
gate will now stay in the par-
tially opened position.
4. Repeat steps 2 and 3 for the
other retaining cable.
When closing the tailgate the
bracket cannot be in the partially
opened position. It must be
anchored on the rear bolt using
the top position on the bracket.
Cargo Management
System (If equipped)
The cargo management system
includes the following items:
• three rails located on the front
and sides of the pickup bed
• four removable and adjustable
cargo tie-downs
NOTICE
Using the horizontal slots on
the top of the pickup box for
tie-down locations may cause
damage to the pickup box and
would not be covered by the
vehicle warranty.
Only use the tie-down loops if
the vehicle does not have the
cargo management system.
The maximum load for each rail is
227 kg (500 lbs).
