XCORE COMPONENTS
6
Wiring Compartment
15 Lithium Battery
The replaceable lithium battery (included) allows the controller to be programmed in the absence
of AC power. In addition, the battery will provide power for backup timekeeping in the event of a
power outage.
16 Internal Junction Box Junction box in outdoor models for making AC power connections
17 Terminal Strip Use to attach transformer, sensor, and valve wires from their source to the controller
18 Reset Button Use to reset the controller (located on right side of controller)
19 REM Allows for connection of Hunter SmartPort
®
and Hunter Remote Controls
20 Sensor Bypass Switch
Ignores “Clik” weather sensor input when in Bypass position
Control Buttons
Button Increases the selected item ashing in the display
Button Decreases the selected item ashing in the display
Button
Returns selected ashing display to previous item
Button
Advances the selected ashing display to the next item
Button
Selects program A, B, or C for dierent watering zone requirements
