Husqvarna AUTOMOWER 310E NERA - Disposal; To Remove the Battery

4. Lift and tilt the top of the charging station.
5. Put the grommet with the cables into position.
6. Connect the cable to the charging station.
7. Connect the power supply unit to the power outlet
and to the charging station.
8. Close the hatch.
8.5 Disposal
• Obey the local recycling requirements and
applicable regulations.
• For questions about how to remove the battery,
refer to
To remove the battery on page 42 .
8.5.1 To remove the battery
1. Set the product to OFF.
2. Remove the body of the product, refer to
To clean
the chassis and body of the product on page 28 .
3. Remove the 12 screws.
4. Remove the warranty seal and lift up the lower
chassis.
5. Disconnect the 2 cables (A) and (B) from the
battery.
A
B
C
6. Disconnect the cable (C) from the front loop circuit
board.
7. Remove the 2 screws for the battery holder.
8. Remove the battery.
42
- Transportation, storage and
disposal
2369 - 001 - 05.02.2024
