15. Chassis with electronics, battery and motors
16. EdgeCut blade disc
17. Main blade disc
18. Handle
19. Contact plates
20. LED indicator of the charging station
21. Hatch
22. Charging station
23. Low-voltage cable
24. Power supply
4
25. Extra blades
26. Screws to attach the charging station
27. Measurement gauge for installation of the
boundary wire (the measurement gauge is
removed from the carton of the product)
28. Operator’s manual and Quick guide
29. Cable markers
30. Alarm decal
31. Stakes
5
32. Loop wire for boundary wire and guide wire
6
33. Connectors for the loop wire
7
34. Couplers for the loop wire
8
35. Reference station EPOS
™
RS1
9
36. Automower
®
EPOS
™
Plug-in
10
2.5 Symbols on the product
These symbols can be found on the product. Make sure
that you understand them.
WARNING: Read the opera-
tor instructions before you op-
erate the product.
WARNING: Disable the prod-
uct before maintenance or
before you lift the product.
WARNING: Keep a safe dis-
tance from the product when
it is in operation. Keep your
hands and feet away from the
rotating blades of the product.
WARNING: Do not sit on
the product. Do not put your
hands or feet near or below
the product.
Use a detachable power sup-
ply as specified on the rating
plate adjacent to the symbol.
This product complies with the applicable
EU Directives.
This product complies with the applicable
UK Directives.
It is not permitted to dispose the product
as usual domestic waste. Obey national
regulations and use the local recycling
system.
The chassis contains components which
are sensitive to electrostatic discharge
(ESD). The chassis must only be opened
and sealed by an authorized service
technician. The warranty will not be
applicable if the seal is broken.
4
The appearance can be different for different markets.
5
Purchased separately.
6
Purchased separately.
7
Purchased separately.
8
Purchased separately.
9
Purchased separately.
10
Purchased separately.
8 - Introduction 2369 - 001 - 05.02.2024
