HUST CNC H6D-B3 MANUAL
29
Appendix 2：Servo Driver Servo-On Connection Diagram
Fig 36 Right and Wrong way of driver connection
Fig 37
Right way:
24V
Servo moving signal
RELAY C
Servo Driver
Servo-On
Si
g
nal
Servo Driver
Servo-On
Signal
Wrong way：
Servo
moving
signal
RELAY C
24V
Servo Driver
Servo-On
Signal
Servo Driver
Servo-On
Signal
TMR T 000
50
msec ＃30
A 0127
O 001
O 001
