HUST CNC H6D-B3 MANUAL
23
12. Bending Machine I/O List
INPUT INFORMATION OUT INFORMATION
0 NC L-axis Limit (hardware ＋) 0 Oil - Stop
1 NC L-axis Limit (hardware －) 1 L-AXIS SERVO-ON
2 NC D-axis Limit (hardware ＋) 2 D-AXIS SERVO-ON
3 NC D-axis Limit (hardware －) 3 R-AXIS SERVO-ON
4 NC Emergent Stop (EM-STOP) 4 NC ALARM
5 5 EM-STOP
6 NO Re-CYCST（Oil Upper Limit） 6
7 NO DX signal（add pressure limit） 7
8 NC L-axis Home Limit 8
9 NC D-axis Home Limit 9
10 NC R-axis Home Limit 10
11 NO MPG –X-axis 11
12 NO MPG –Y-axis 12
13 NO MPG –Z-axis 13
14 NO MPG × 1 14
15 NO MPG × 10 15
16 NO MPG × 100
17 NC R-axis Limit (hardware ＋)
18 NC R-axis Limit (hardware －)
19
20 NO “CYCST” key unused
21
22
23
NO：Normally-Open NC：Normally-Close
OT limit and HOME limit can be found in the parameter page 2. They are set as
Normally-Open or Normally-Close. And the default is Normally-Close.
